| A) | Electrical Input | 230V / 115 V AC, 50Hz |
| B) | DIMENSIONS | Main Unit |
| Unit Size | L 280mm X B 265mm X H 120mm | |
| Unit Weight | 4.7 Kg | |
| C) | Optical Sensors | Directional Reflectance |
| Lamp Source | Tungston ‘A’ Source | |
| Geometry | Incidence 00 – Reflectance 450 | |
| Filter | Built-in Filter Sensors | |
| Sample Area | Circle 18mm Diameter | |
| D) | Zero STD. | Cavity [ Black Body ] |
| Ceramic Tile STD. | Calibrated with respect to BaSO4 As per ISO Standards. | |
| E) | LCD Display | Range 0 % to 999.9 % Stable & Repeatable Results |
| Microprocessor meter having built-in calibration program |
| Input | 230V / 115V a.c |
| DIMENSIONS | L 280mm X B 265mm X H 120mm |
| Unit Weight | 4.7 Kg (main Unit) |
| Optical Sensor | |
| Lamp Source | Daylight D 65 |
| Geometry | 750 Incidence – 750 Reflectance |
| Sample Area | 85mm X 20mm (Oblong) |
| Standards suppied | – |
| Zero | Black = 0 Units |
| Gloss 100 Units | – |
| LCD Display | 0% – 999.9 % |
| Microprocessor meter having built-in calibration program |
